Technical specifications 60W

TYPE	Single leaf	Double leaves
Model	RADOS-100F-S(60W)	RADOS-100F-D(60W)
Power supply	AC 220V(50~60Hz)
Controller	Micro-Processor Control
DC gear motor	DC 24V 60W Gear Motor
Drive	S8M Timing Belt
Maximum door weight	120Kg X 1	80Kg X 2
Opening speed	350mm ~ 1000 mm / sec (Adjustable)
Closing speed	150mm ~ 850mm / sec (Adjustable)
Min~Max clear width	700mm ~ 1200 mm X 1	700mm ~ 1200mm X 2
Hold open time	0~20 sec
Safety function	Safety reverse
Ambient temp	-30℃ ~ +50℃

Technical specifications 90W

TYPE	Single leaf	Double leaves
Model	RADOS-100F-S(90W)	RADOS-100F-D(90W)
Power supply	AC 220V(50~60Hz)
Controller	Micro-Processor Control
DC gear motor	DC 24V 90W Gear Motor
Drive	S8M Timing Belt
Maximum door weight	150Kg X 1	100Kg X 2
Opening speed	350mm ~ 1000 mm / sec (Adjustable)
Closing speed	150mm ~ 850mm / sec (Adjustable)
Min~Max clear width	700mm ~ 1500 mm X 1	700mm ~ 1500mm X 2
Hold open time	0~20 sec
Safety function	Safety reverse
Ambient temp	-30℃ ~ +50℃
